Sekonic C-7000 Spectrometer Bundle Kit

SKU: 401-711 | FREE U.S. shipping!

  • * with the latest firmware
  • Measures LED, HMI, Fluorescent, Tungsten, Natural Light and Flash, from 380 to 780nm
  • Wide measurement range of Color Temperature (1,563 to 100,000K) and illuminance (1 to 200,000lx in ambient light, 20 to 20,500lx・s in flash light)
  • Conforms to Class A of JIS C 1609-1: 2006, and DIN 5032 Part 7 Class C as Illuminance meter class
  • Text Mode with more measurement for Industrial use such as Tcp, ⊿uv, XYZ, λd, λp, Pe
  • Spectrum Mode / Spectrum Comparison Mode
  • PPFD (Photosynthetic Photon Flux Density) Measurement
  • Expanded Color Rendering Properties (CRI/CRI Comparison, SSI, TLCI, TLMF, TM-30-18) *
  • CIE1931 (CIE1964) Chromaticity Coodinates and CIE1931 (CIE1964) Comparison Mode
  • CIE1976 Chromaticity Coodinates and CIE1976 Comparison Mode
  • 2°or 10° field of view is selectable
  • Single / Continuous measurement *
  • Exposure time (Shutter speed) is selectable
  • Up to 999 measurements can be stored in memory
  • User-friendly design: 270 degrees swivel head, dark calibration without a cap, large 4.3” color touch panel LCD and Customize function
  • C-7000 Utility offers easy setting, updating firmware of the meter, and outputting the various graphics and csv data
  • 1nm / 5nm increment spectrum output in CSV format by Utility
  • SDK (Software Development Kit) for remote control is available
Write a Review

Overview

The SPECTROMASTER C-7000 is a portable handheld spectrometer, designed especially for industrial use. Utilizing Sekonic’s CMOS linear image sensor design and large touch-screen color display, the C-7000 can measure and accurately describe LED, HMI, fluorescent, as well as natural light and electronic flash. The C-7000’s Utility software displays memorized data in several ways and outputs spectral data in 1nm/5nm (nanometer) increments in CSV format. The C-7000 is an important measuring tool for quality control in lamp manufacturing, medical facilities, educational / office safety and health standards, agricultural lighting / design and many more industrial uses.

Specifications

Catalog Numbers:

SKU:
401-711
Family:
L-858D
Sensor:
CMOS linear image sensor
Measuring System:
Spectro Meter
Incident light: Swivel head
Measuring Range and Modes:

Measuring Modes (Ambient Light):
Ambient light
Measuring Modes (Flash light):
Cordless, Cord-in (PC)
Measuring Range at ISO100 (Ambient Incident Light):
1 lx to 200,000 lx *
0.1 fc to 18,600 fc

* Class A of JIS C 1609-1: 2006 “Illuminance meters Part 1: General measuring instruments”
Measuring Range (Flash Incident Light):
20 lx・s to 20,500lx・s
1.86 fc・s to 1,900 fc・s
Spectral Wavelength Range:
380nm to 780nm
Color Measuring Mode (Display Mode):
Text mode, Spectrum mode, Spectrum Comparison mode, CRI mode, CRI Comparison mode, TM-30-18 mode, SSI mode, TLCI/TLMF mode, CIE1931 (CIE1964) mode, CIE1931 (CIE1964) Comparison mode, CIE1976 mode, CIE1976 Comparison mode
Color Measuring Range (Ambient Light):
1,563 to 100,000K
Color Measuring Range (Flash Light):
2,500 to 100,000K
Color Measuring Units (Color Parameters):
Correlated Color Temperature (Tcp),Deviation (⊿uv ), Tristimulus value (XYZ / X10Y10Z10), CIE1931/1964 (xyz / x10y10z10), CIE1976 (u’v’ / u’10v’10 ),
Color Measuring Units (Color Rendering Properties):
CRI (Ra /R1 to R15), TM-30-18 (Rf, Rg), SSI(t, d, 1, 2) TLCI, TLMF
Color Measuring Units (Industrial):
Dominant wavelength (Λd), Excitation purity (Pe), Peak wavelength (Λp), PPFD,
Color Measuring Units (Photo/Cinematography):
Dominant wavelength (Λd), Excitation purity (Pe), Peak wavelength (Λp), PPFD,
Shutter Speeds Range (Ambient Light):
Auto - Max.: 15 sec., Min.: 0.5 sec.
Manual - 0.1s, 1sec.
Shutter Speeds Range (Flash Light):
1 to 1/500 sec. (in 1 step)
Memory:
Yes (999 times)
Contrast/Comparison Function:
Yes
Custom Settings:
Yes (5 custom settings)
Measuring Data Output:
Memorized value with graphic
Spectral irradiance from 380nm to 780nm in 1 and 5 nm increments
Physical:

Tripod Socket:
Yes
Operating Temperature:
-10 deg. C to 40 deg. C
Storage Temperature:
-10 deg. C to 60 deg. C
Power Source:
1.5V x 2 (AAA battery)
LCD:
4.3" color dot matrix touch panel LCD
LCD Backlight:
Yes
Product Weight (lb):
0.51
Product Weight (kg):
0.23
Product Height (in):
1.06
Product Length (in):
7.2
Product Width (in):
2.87
Product Height (cm):
2.7
Product Length (cm):
18.3
Product Width (cm):
7.3

WHAT'S IN THE BOX

Software

CAUTION!: Do not connect C-800 meter with C-700/7000 Utility. C-800 meter can be downgraded to C-700.

Note: Please read the "Compatibility and Update between C-800/C-7000 Firmware and Utility due to product name change" before you begin.

MAC OS C-700/7000 Series Utility

IMPORTANT!:

  1. READ ME FIRST before you begin.
  2. Please see the Software Guide for installation.

  3. Turn off firewalls and anti-virus programs during the installation process.



Version 3.01.00 for MAC Download C-700_7000 Series Utility for OSX 10.15 - 13 (221 MB)

WINDOWS C-700/7000 Series Utility

IMPORTANT!:

  1. READ ME FIRST before you begin.
  2. Please see the Software Guide for installation.

  3. Turn off firewalls and anti-virus programs during the installation process.



Version 3.01.00 for Windows Download C-700_7000 Series Utility for Windows 10 - 11 (265 MB)

Spectrometer C-7000 SDK (Software Development Kit)

IMPORTANT!:

  1. Please note that any questions, improvement requests or technical inquiries regarding SDK usage are not supported.
  2. If you want to get C-7000 SDK, it is required to fill in the form and send it back to a local distributor in your country. We will contact you after receiving the form. Please download the application form below.

​Download C-7000 SDK Application Form


Software Guides (PDF)

The Screens of C-7000 Utility Software

CAUTION!: NOTE: 1nm / 5nm increment spectrum output in CSV format by Utility can be done by C-7000 Only.

Firmware

Sekonic C-7000 Spectrometer Bundle Kit Firmware

Manuals
